UV Sterilization Truck

Application range:

Used for air sterilization in all sorts of sanitary medical units or departments, scientific research units, pharmaceutical and food-process industry, etc.
Structure features
• Double tubes structure, which can also be used independently.
• Angle of lamp arm can be adjusted. In order to protect tubes from dust and damage, please leave protection door shut while it doesn't work.
• Sterilization timing range: 0~ 60 minutes for sterilization. Once sterilization is finished, buzzer rings, circuit breaks down and pipe turns off.
• Do circuit test before use to make sure if there is no leakage prior to application.

Main Technical Data
UV Wavelength: 253.7mm
Power Source: AC220V (50HZ)
Adjustment angle of lamp arm: 0-135° (II model)
Timing range: 0~60 minutes ( ZXC-II (SG/SGB) model) 0~99 minutes (ZXC-III (PW) model)
Illumination: 100μw/cm²
Light: Quartz light tube for II/III model 30W x2
Quartz light tube for SG/SGB model 30W x4

ZXC-III(PW)
Infrared remote control type, electric timing

ZXC-III(PY)

steel, spray(double-lamp)

ZXC-II(PY)
Steel coated with powder (Double tubes)

ZXC-II(XY)
Steel coated with powder (Double tubes)

ZXC-II(SG)
Steel coated with powder (Four tubes)

ZXC-II(SGB)
Steel coated with powder (Double tubes)

Having Nearly 40 Years of Experience with Two Factories


Founded in 1974, Shanghai Yuejin which is the parent company of Shanghai Hengyue Medical Instruments Co. Ltd, owns two factories in Shanghai, China. One of which is the medical optical factory that specializes in ENT diagnostic sets, X-ray implements, infrared therapy lamps and nursing instruments, and the other is the incubator factory that offers all kinds of incubators and drying ovens for medical or laboratory use. We have an experienced team to develop, produce and distribute our goods. OEM orders are welcome.
